IoT Omni Antenna – 915MHz
IoT Omni Antenna – 915MHz
$97.00
The IoT Omni Antenna is a 915MHZ LoRa Omni antenna that is suitable for outdoor or indoor use. Suitable for IoT devices running on 915Mhz
In stock
In stock
Additional information
| Weight | 2 kg |
|---|---|
| Dimensions | 60 × 10 × 10 cm |
| LMR240 Cable | N Male – RPSMA x 5m, N Male – RPSMA x 10m |
More information about IoT Omni Antenna – 915MHz
IoT Omni Antenna – 915MHZ
The IoT Omni Antenna is a 915MHZ LoRa Omni antenna that is suitable for outdoor or indoor use. The Industrial grade construction and durable fiberglass radome provide excellent waterproof resistance and high temperature performance.
The IoT 915Mhz antenna has a 5.8dBi gain, and is recommended as a direct replacement to the factory antennas for IoT devices to maximize coverage.
IoT Antenna Specifications
| Electrical specifications | |
| Frequency Range(MHz) |
915MHz |
| Impedance(ohm) |
50 |
| Gain (dBi) |
5.8 |
| Polarization |
Vertical |
| Radiation |
Omni |
| VSWR |
≤1.5 |
| Maximum input power (W) |
50 |
| Mechanical specifications | |
| Connector |
N-Female |
| Height |
600mm |
| Radome Material |
FiberGlass |
| Color |
White |
| Weight |
0.4Kg |
| Operating temperature (℃) |
-50～80 |
