LL400 Coaxial Cable, N Male to N Male
LL400 Coaxial Cable, N Male to N Male
$74.00 – $194.00
LL400 Type Foam Low – Loss 50 Ohm Coaxial Cable with N Male to N Male fittings
In stock
Additional information
| Weight | 5 kg |
|---|---|
| Dimensions | 60 × 30 × 10 cm |
| Choose Your Cable Length: | 10m, 15m, 20m, 25m, 30m, 35m, 40m |
More information about LL400 Coaxial Cable, N Male to N Male
Our pre-made LL400 cables range from 10m to 40m if you require longer or shorter lengths please contact us.
Description:
LL400 Type Foam Low – Loss 50 Ohm Coaxial Cable with N Male to N Male fittings
Electrical characteristics:
- Nom. Impedance: 50 Ohms
- Nom. Inductance: 0.060 micro-h/ft
- Nom. Capacitance: Conductor to shield: 77.1 pf/m
- Nom. Velocity of propagation: 85 %
- Nom. Delay 1.20 ns/ft
- Nom. Conductor dc resistance: @ 20 deg. C: 1.39 ohms/1000 ft.
- Nom. Shield dc resistance @ 20 deg. C: 1.65 ohms/1000 ft.
- Max. Operating voltage: 300 vrms (non-ul)
- Voltage standing wave ratio: 5- 5000 MHz 1.20:1 (20dB)
- (Return Loss)
- 800-1000MHz 1.10:1 (26dB)
- 1700-2000MHz 1.15:1 (23dB)
- 2000-2400MHz 1.15:1 (23dB)
Nom. Attenuation & Power Rating
Frequency (MHz) |
Nom. Attenuation (dB/100m) |
Avg Power Rating (Kwatts @ 20oC) |
| 900Mhz | 12.80dB | 0.50Kw |
| 1800Mhz | 18.60dB | 0.34Kw |
| 2500Mhz | 22.20dB | 0.29Kw |
| 5800Mhz | 35.50dB | 0.18Kw |
Physical characteristics:
- Temperature rating: -40 to +85 deg. C
- Min. Bending radius: 51mm
- Max. Pulling tension: 221.0 lbs.
- Nom. Weight/1000 ft: 105 lbs.
- Conductor material & dia: Solid Copper @ 2.74mm
- Insulation material & dia: Physical Foam PE, 7.24mm
- Shield type & % coverage & dia: Aluminium Tape – 100% TC braid – 88% – 8.13mm
- Jacket material & dia PE (black), 10.3mm
Please Note : All performance data contained herein are calculated based On nominal dimensions and material properties. Actual Performance may vary.
